CAT50 ALIGNMENT GAGE TOOL HOLDER MADE IN USA

In Stock

SKU: CAT50ALIGNMENT

$199.99

CAT50 ALIGNMENT GAGE TOOL HOLDER MADE IN USA

TEST BAR INCLUDED

Qty
Compare

CAT50 ALIGNMENT GAGE TOOL HOLDER MADE IN USA

MODEL CAT50 ALIGNMENT  RUN OUT (TIR) 0.0002″
HOLDER TYPE  ALIGNMENT TOOL HOLDER ARBOR DIAMETER 1″
SHANK TYPE CAT50 DRAWBAR THREAD 1-8″
BALANCE NO Gage Length 2.5″



CAT50 ALIGNMENT GAGE TOOL HOLDER MADE IN USA

High Precision Runout: TIR  5μm or 0.0002



Drawings & Parameters Table



CAT50 TAPER 8° TAPER D1 L1 FLANGE D
DRAWBAR THREAD CAT50 1-8″  UNC 2.75″ 2.69″ 3.875″



Weight 1.5 lbs
Dimensions 15 × 45 × 65 in
Measurement system

Inch (in)

Product Category

Alignment Gage Tool Holder

Shank Type

CAT50
