ULTRA PRECISION 1MM ER8 ER COLLET TIR 0.01/0.0004″ 1pcs

In Stock

SKU: UER801001M

$11.99

iCarbide ER8 collet Spec

Works on all ER Collet Chuck Holder

  • Material: High-performance spring steel
  • Finishing & Rough Cutting: All surfaces precision ground; Twice heat treatment
  • Run Out (TIR): TIR 0.01/0.0004″
  • Hardened: HRC48
  • Size includes: 1mm
  • Collets Color: Oxide Black

Concentricity is less than .0001 and 0.0005 at collet face available.

Qty
Compare

ULTRA PRECISION ER COLLET

OUR FEATURES

  • Use spring steel from Japan and Germany, Taiwan.
  • SUJ2 after heat treatment, has high hardness(hrc48) and toughness, better grinding quality, good flexibility, and longer useful life.
  • All ER Collet 100% QC, keep each collet are in good run out condition, run out checking with 4 times long, using Rego-fix, Collet QC system, 99% collet run out under 3 μm and 3t Time confirmed for your machining.

ULTRA PRECITION COLLET APPLICATION

ER collets are widely used in CNC machining for their strong clamping force, wide tool size range, and accuracy. They support various machine tool series and machining tasks, including boring, milling, drilling, tapping, grinding, and carving. These versatile collets are crucial for maintaining precision and efficiency in machining operations.

ultra-precision-er-collet-icarbide-1200x1200-2

MORE SPECS FOR ULTRA ER COLLETS

We sold quantity over  500,000 pieces per year

100% REFUND GUARANTEE RESPECT

It is a kind of collet chuck with large tightening force, wide clamping range, and good precision. Generally used for supporting the use of CNC collet tool holders.

Product TypeSize Range / mmTIRDL
ER81.0 ~ 5.50.01/0.0058.513.5
ER111.0 ~ 7.00.01/0.00511.518
ER161.0 ~ 100.01/0.0051727.5
ER201.0 ~ 130.01/0.0052131.5
ER252.0 ~ 160.01/0.0052634
ER322.0 ~ 200.01/0.0053340
ER403.0 ~ 260.01/0.0054146
ER506.0 ~ 300.01/0.0055260

Search SKU and order now!

ER8 Ultra Precision ER Collets

Order SKUCollet TypesCollet SeriesClamping RangeRun Out (TIR)Price
UER8105001MUltra Precision ER ColletER81.5MM0.0111.99
UER81050005MUltra Precision ER ColletER81.5MM0.00514.99
UER801001MUltra Precision ER ColletER81MM0.0111.99
UER8010005MUltra Precision ER ColletER81MM0.00514.99
UER8205001MUltra Precision ER ColletER82.5MM0.017.99
UER82050005MUltra Precision ER ColletER82.5MM0.00510.99
UER802001MUltra Precision ER ColletER82MM0.0111.99
UER8020005MUltra Precision ER ColletER82MM0.00514.99
UER8305001MUltra Precision ER ColletER83.5MM0.017.99
UER83050005MUltra Precision ER ColletER83.5MM0.00510.99
UER803001MUltra Precision ER ColletER83MM0.017.99
UER8030005MUltra Precision ER ColletER83MM0.00510.99
UER8405001MUltra Precision ER ColletER84.5MM0.017.99
UER84050005MUltra Precision ER ColletER84.5MM0.00510.99
UER804001MUltra Precision ER ColletER84MM0.017.99
UER8040005MUltra Precision ER ColletER84MM0.00510.99
UER8505001MUltra Precision ER ColletER85.5MM0.017.99
UER85050005MUltra Precision ER ColletER85.5MM0.00510.99
UER805001MUltra Precision ER ColletER85MM0.017.99
UER8050005MUltra Precision ER ColletER85MM0.00510.99
Weight 0.22 lbs
Measurement system

Metric (mm)

Product Category

Ultra Precision ER Collet

Collet Series

ER8

Clamping Range

1MM

Run Out (TIR)

0.01
